• 12V Cranking Lead Acid Battery Test
• 12/24V Charging or Cranking System Test
• Display Battery Capacity, Voltage, Resistance and Life
• Four-Terminal Kelvin Test
• 10 Types of Battery Standards
• Language Option (Chinese/English)
• Test without Battery Disassembly
• LED Color Indication for Test Result (UT673A)

Specifications:

• Certificates: CE, FCC, RoHS

• 12 Volt Battery Test: 7~16V DC
• 12V / 24V Cranking System Test: 7~30V DC
• 12V / 24V Charging System Test: 7~30V DC
• Battery Type: Oridinary Lead Acid Battery, AGM Flat Plate Battery, AGM Spiral Battery, GEL Battery, EFB Battery
• Battery Capacity: 3~250AH
• Battery Standard and Range: CCA: 40~2000; BCI: 40~2000; CA: 40~2000; MCA: 40~2000; JIS: 26A17~245H52; DIN: 40~1400;
• IEC: 40~1400; EN: 40~2000; SAE: 40~2000; AH: 3~250AH
• Over Voltage Protection: Yes
• Reverse Connection Protection: Yes
• A Prompt of Poor Contact: Yes
• Battery Status Display: Yes
• Battery Life Display: Yes
• Battery Capacity Display: Yes
• Battery Internal Resistance Display: Yes
• Power: None, Powered by External Source
• Display: 128 x 64 Black & White Lattice
• Product Net Weight: 264 Grams
• Product Size: 76mm x 22mm x 142mm
